Scale Drawings
by John Hawley

The drawings that Harrye worked to when building his Lion were produced by John Hawley. Harrye is indebted to John for all the work he has done and the fact is that without these drawings he could not have built his engine.

Much reduced in size examples of the drawings, these do not do justice to their original quality.
please click on images to see larger pictures

A list of his drawings is shown below.

To contact him please E-mail John at:

Prototype Lion Drawings in Preparation (See Note 1)

Sketch No. *(See Note 2)*	Description *(See Note 3)*	Size (ins)	With Dimn?	Comments	CAD or Hand Drawn
0	Left elev of loco & tender with OLCO heading	24 x 62	No	For display, etc., not for modeling	C
1 (GA)	Left elev of loco & tender + plan, front & rear elevs of loco	24 x 49	Yes	Includes Tender same scale, but not dimensioned	C
2	Right elev of loco only	24 x 37	Some	1/8^th scale	C + H
3-5	-	-	-	-	-
6	Boiler for 7 ¼” gauge	24 x 47	Yes	Incomplete. Unsuitable for modelling	C
7	GA of boiler	24 x 48	Yes		H
8	Boiler Fittings: (Clack, safety valve & whistle)	24 x 47	Yes		H
9	Haycock & Lagging	24 x 33	Yes		H

10/1	Driving wheels & front axle	24 x 48	Yes		C
10/2	Crank axle, eccentrics, etc.	24 x 44	Yes		C
10/3	Trailing & tender wheels/axles	24 x 45	Yes		C

11	GA of main frame			Not Started. Most info on GA
12	Inner frames	24 x 46	Yes		C

13/1	Smokebox – external	24 x 39	Yes		C
13/2	Smokebox – internal	24 x 42	Yes	Includes basic info on valves & cylinders	H
14	Chimney	24 x 33	Yes		C
15	Drive Motion: Piston & rod, crosshead, big/small ends, con rod plus keys and assembly details.	24 x 48	Yes		C
16	Cylinder covers, motion plate slide bars & valve rocking lever	24 x 47	Yes		H
17	Weighshaft on rear of smokebox, plus gab rod	12 x 21	Yes		C
18	Reversing lever	24 x 33	Yes		C
19	Water pump details & installation	24 x 45	Yes		H
20	Firedoor & Water gauge	24 x 33	Yes		C
21/1	Footplate	24 x 33	Yes		H
21/2	Cab Side Railings	24 x 33	Yes		H
21/3	Stirrup Step	12 x 17	Yes		C
22	Regulator	24 x 33	Yes		C
23	Connecting Link (‘Dogbone’)	12 x 17	Yes		H
24	Coupling Rod & Fly Crank	24 x 33	Yes		C
31	Tender			Not Started. See GA

Note 1:

All drawings are of prototype Lion unless stated.

Most are to some degree incomplete, but further information may be available on request.

Note 2:

A drawing numbering system has yet to be devised. For now, a simple sketch number and title are the only identifiers.

Note 3:

Major assemblies are shown in bold type, with their sub-assemblies or individual parts listed in normal type.

Many items are missing, but will be added to the list as and when draw
